TM 9-2320-360-34-1
NOTE
Supply brakes are equipped with
solenoids. Do step (17) for supply
brakes only.
(17)
Remove solenoid valve wire (34) and
spade connector (35) from solenoid valve
(36).
(18)
Loosen connector nut (37) between right
brake (38) and left brake (39).
NOTE
Forward brake set on left side is
shown.
(19)
Screw connector (40) into left brake (39)
to clear right brake (38).
(20)
Remove two screws (41) and brake (38 or
39) from two mounting posts (42).
3-143
|
