TM 9-2320-360-34-1
4-5. AIR INLET HOUSING/ADAPTER REPLACEMENT (CONT)
c.
Installation
NOTE
Gaskets should be positioned with
rubber seal facing up.
(1)
Install 2 new preformed packings (1), new
gasket (2), and air inlet housing (3) on
blower (4) with 10 new lockwashers (5)
and screws (6). Torque to 45 Ib-ft (61
Nm) starting with center screws and
working out toward each end.
WARNING
Adhesive-sealant can burn easily,
can give off harmful vapors, and is
harmful to skin and clothing. To
avoid injury or death, keep away from
open fire and use in well-ventilated
area. If adhesive-sealant gets on skin
or clothing, wash immediately with
soap and water.
(1.1)
Coat threads on three screws (7) and
screw (7.1) with adhesive-sealant.
(2)
Install new gasket (8), adapter (9), and
bracket (10) on air inlet housing (3) with
three screws (7) and screw (7.1). Torque
to 240 lb-in. (27.1 Nm).
4-18
|
