TM 9-2320-360-34-1
3-28. ENGINE TESTING (CONT)
WARNING
·
Exhaust manifolds and engine
parts are hot. Use care to prevent
personal injury.
· Use caution when working near
hood
mounting
bracket
that
extends beyond firewall. Failure
to comply may result in injury to
personnel.
CAUTION
Clean around rocker cover before
removing each cover from engine.
This will keep dust or dirt from
entering cylinder heads.
NOTE
·
Right
and
left
side
cylinder
compression
checks
are
performed in the same manner.
·
Both rocker covers are replaced
in a similar manner. Right cover
is shown.
·
Do steps (1) thru (10) for right
rocker cover only.
(3)
Remove two nuts (1), lockwashers (2),
screws (3), and lower band (4) from
steering
reservoir
(5).
Discard
lockwashers.
WARNING
Support steering reservoir before
loosening band. Failure to comply
may result in injury to personnel.
(4)
Loosen two nuts (6).
(5)
Raise steering reservoir (5) about 5 in. (13
cm) and support.
(6)
Tighten two nuts (6).
3-140 Change 3
|
